Lens Mount

E-mount

Aspect Ratio

3:2

Number Of Pixels (Effective)

Approx. 24.2 megapixels

Number of Pixels (total)

Approx. 25.3 megapixels

Sensor type

35 mm full-frame (35.6 x 23.8 mm), Exmor R CMOS sensor

Anti-Dust System

Yes (Charge protection coating on optical filter and image sensor shift mechanism)

IMAGE SIZE (PIXELS) [4:3]

35 mm full-frame L: 5328 x 4000 (21M), M: 3488 x 2624 (9.2M), S: 2656 x 2000 (5.3M), APS-C L: 3488 x 2624 (9.2M), M: 2656 x 2000 (5.3M), S: 1744 x 1312 (2.3M)

Image Size (pixels) [16:9]

35 mm full-frame L: 6000 x 3376 (20M), M: 3936 x 2216 (8.7M), S: 3008 x 1688 (5.1M), APS-C L: 3936 x 2216 (8.7M), M: 3008 x 1688 (5.1M), S: 1968 x 1112 (2.2M)

IMAGE SIZE (PIXELS) [1:1]

35 mm full-frame L: 4000 x 4000 (16M), M: 2624 x 2624 (6.9M), S: 2000 x 2000 (4.0M), APS-C L: 2624 x 2624 (6.9M), M: 2000 x 2000 (4.0M), S: 1312 x 1312 (1.7M)

14bit RAW

Yes

Picture Effect

8 types: Toy Camera (Normal / Cool / Warm / Green / Magenta), Pop Colour, Posterisation (Colour, B/W), Retro Photo, Soft High-key, Partial Colour (R/G/B/Y), High Contrast Monochrome, Rich-tone Monochrome

Creative Style

Standard, Vivid, Neutral, Clear, Deep, Light, Portrait, Landscape, Sunset, Night Scene, Autumn leaves, Black & White, Sepia, Style Box (1–6)

Picture Profile

Yes (Off/PP1-PP10) Parameters: Black level, Gamma (Movie, Still, Cine1-4, ITU709, ITU709 [800%], S-Log2, S-Log3, HLG, HLG1-3), Black Gamma, Knee, Colour Mode, Saturation, Colour Phase, Colour Depth, Detail, Copy, Reset

CREATIVE LOOK

-

Dynamic Range Functions

Off, Dynamic Range Optimiser, Auto High Dynamic Range

Colour Space

sRGB standard (with sYCC gamut) and Adobe RGB standard compatible with TRILUMINOS Colour

Recording Format

JPEG (DCF Ver. 2.0, Exif Ver.2.32, MPF Baseline compliant), RAW (Sony ARW 2.3 format)

Image Size (pixels) [3:2]

35 mm full-frame L: 6000 x 4000 (24M), M: 3936 x 2624 (10M), S: 3008 x 2000 (6.0M), APS-C L: 3936 x 2624 (10M), M: 3008 x 2000 (6.0M), S: 1968 x 1312 (2.6M)

Image Quality Modes

RAW (Compressed / Uncompressed), JPEG (Extra fine / Fine / Standard), RAW & JPEG

Recording Format

XAVC S

Colour Space

xvYCC standard (x.v.Colour when connected via HDMI cable) compatible with TRILUMINOS Colour

Picture Effect

7 types: Toy Camera (Normal / Cool / Warm / Green / Magenta), Pop Colour, Posterisation (Colour, B/W), Retro Photo, Soft High-key, Partial Colour (R/G/B/Y), High Contrast Monochrome

Creative Style

Standard, Vivid, Neutral, Clear, Deep, Light, Portrait, Landscape, Sunset, Night Scene, Autumn leaves, Black & White, Sepia, Style Box (1–6)

Picture Profile

Yes (Off/PP1-PP10) Parameters: Black level, Gamma (Movie, Still, Cine1-4, ITU709, ITU709 [800%], S-Log2, S-Log3, HLG, HLG1-3), Black Gamma, Knee, Colour Mode, Saturation, Colour Phase, Colour Depth, Detail, Copy, Reset

CREATIVE LOOK

-

MOVIE RECORDING SYSTEM (XAVC S 4K)

3840 x 2160 (4:2:0, 8 bit, NTSC) (Approx.) 30p (100 Mbps / 60 Mbps), 3840 x 2160 (4:2:0, 8 bit, NTSC) (Approx.) 24p (100 Mbps / 60 Mbps), 3840 x 2160 (4:2:0, 8 bit, PAL) (Approx.) 25p (100 Mbps / 60 Mbps)

MOVIE RECORDING SYSTEM (XAVC S HD)

1920 x 1080 (4:2:0, 8 bit, NTSC) (Approx.) 120p (100 Mbps / 60 Mbps), 1920 x 1080 (4:2:0, 8 bit, NTSC) (Approx.) 60p (50 Mbps / 25 Mbps), 1920 x 1080 (4:2:0, 8 bit, NTSC) (Approx.) 30p (50 Mbps / 16 Mbps), 1920 x 1080 (4:2:0, 8 bit, NTSC) (Approx.) 24p (50 Mbps), 1920 x 1080 (4:2:0, 8 bit, PAL) (Approx.) 100p (100 Mbps / 60 Mbps), 1920 x 1080 (4:2:0, 8 bit, PAL) (Approx.) 50p (50 Mbps / 25 Mbps), 1920 x 1080 (4:2:0, 8 bit, PAL) (Approx.) 25p (50 Mbps / 16 Mbps)

Slow and quick motion (shooting frame rate)

NTSC mode: 1fps, 2fps, 4fps, 8fps, 15fps, 30fps, 60fps, 120fps, PAL mode: 1fps, 2fps, 3fps, 6fps, 12fps, 25fps, 50fps, 100fps

Movie Functions

Audio Level Display, Audio Rec Level, PAL/NTSC Selector, TC/UB, Auto Slow Shutter, Gamma Disp. Assist

VIDEO COMPRESSION

XAVC S: MPEG-4 AVC/H.264

AUDIO RECORDING FORMAT

XAVC S: LPCM 2ch

Location information Link from smartphone

Yes

Media

SD memory card, SDHC memory card (UHS-I/II compliant), SDXC memory card (UHS-I/II compliant)

Memory Card Slot

Slot for SD (UHS-I/II compliant) memory card

Recording mode on 2 memory cards

-

Noise Reduction

Long exposure NR: On / Off, available at shutter speeds longer than 1 s, High ISO NR: Normal / Low / Off

White Balance Modes

Auto / Daylight / Shade / Cloudy / Incandescent / Fluorescent / Flash / Underwater / Colour Temperature (2500 to 9900K) & colour filter / Custom

SHUTTER AWB LOCK

Yes (Shut. Halfway Down / Cont. Shooting / Off)

Focus Type

Fast Hybrid AF (phase-detection AF / contrast-detection AF)

Focus Sensor

Exmor R® CMOS sensor

Focus Point

35 mm full frame: 693 points (phase-detection AF), APS-C mode with FF lens: 299 points (phase-detection AF), with APS-C lens: 221 points (phase-detection AF) / 425 points (contrast-detection AF)

Focus Sensitivity Range

EV–4 to EV20 (ISO 100 equivalent with F2.0 lens attached)

Focus Mode

AF-A (Automatic AF), AF-S (Single-shot AF), AF-C (Continuous AF), DMF (Direct Manual Focus), Manual Focus

Focus Area

Wide / Zone / Centre / Flexible Spot / Expanded Flexible Spot / Tracking

EYE AF / SUBJECT RECOGNITION AF

[Still images] Human (Right/Left Eye Select) / Animal, [Movie] Human (Right/Left Eye Select) / Animal

Other Features

Eye-start AF (only with LA-EA2 or LA-EA4 attached [Sold separately]), AF micro adjustment (with LA-EA2 or LA-EA4 [Sold separately]), Predictive control, Focus lock, AF Track Sens. (Still), AF Subj. Shift Sensitivity (Movie), AF Transition Speed (Movie), Switch V/H AF Area, AF Area Regist., Circ. of Focus Point

AF Illuminator

Yes (with Built-in LED type)

AF Illuminator range

Approx. 0.3 m—approx. 3.0 m (with FE 28–70 mm F3.5-5.6 OSS lens attached)

Focus type with LA-EA3 (Sold separately)

Phase-detection

Metering Sensor

Exmor R® CMOS sensor

Metering Sensitivity

EV-3 to EV20 (ISO100 equivalent with F2.0 lens attached)

Metering Mode

Multi-segment, Centre-weighted, Spot (Standard/Large), Entire Screen Avg., Highlight

Exposure Compensation

/- 5.0 EV (1/3 EV, 1/2 EV steps selectable) (with exposure compensation dial: /- 3 EV [1/3 EV steps])

Exposure Bracketing

Bracket: Cont., Bracket: Single, 3/5/9 frames selectable. (Ambient light, Flash light)

AE Lock

Locked when shutter button is pressed halfway. (On/Off/Auto)

Exposure Modes

AUTO (Intelligent AUTO), Programmed AE (P), Aperture priority (A), Shutter-speed priority (S), Manual (M), Movie (Programmed AE [P] / Aperture priority [A] / Shutter-speed priority [S] / Manual [M]), Slow & Quick Motion (Programmed AE [P] / Aperture priority [A] / Shutter-speed priority [S] / Manual [M])

ISO Sensitivity

Still images: ISO 100–51200 (ISO numbers up from ISO 50 to ISO 204800 can be set as expanded ISO range), AUTO (ISO 100–12800, selectable lower limit and upper limit), Movies: ISO 100–51200 equivalent (ISO numbers up ISO 102400 can be set as expanded ISO range), AUTO (ISO 100–12800, selectable lower limit and upper limit)

Anti-Flicker Shoot.

Yes

Scene Selection

-

Metering Type

1200-zone evaluative metering

Viewfinder Type

1 cm (0.39 type) electronic viewfinder (XGA OLED)

Number of Dots

2,359,296 dots

Field Coverage

100%

Magnification

Approx. 0.59x (with 50 mm lens at infinity, –1 m–1)

Dioptre Adjustment

-4.0 to 3.0 m-1

Eye Point

Approx. 20 mm from the eyepiece lens, 17.5 mm from the eyepiece frame at –1 m–1 (CIPA standard)

DISPLAY FUNCTION

Histogram, Real-time image-adjustment display, Digital level gauge, Grid line, Focus check, Peaking MF, Zebra, Movie marker, For viewfinder, Monitor Off

Finder Frame Rate Selection

NTSC mode: STD 60fps/HI 120fps, PAL mode: STD 50fps/HI 100fps

Monitor Type

7.5 cm (3.0-type) type TFT

Touch Panel

Yes (Touch shutter / Touch focus / Touch pad / Touch tracking)

Number of Dots

921,600 dots

Brightness Control

Manual (5 steps between -2 and 2), Sunny Weather mode

Adjustable Angle

Opening angle: Approx. 176 °, Rotation angle: Approx. 270 °

Focus Magnifier

Yes, Focus Magnifier (35 mm full-frame: 5.9x / 11.7x, APS-C: 3.8x / 7.7x)

PlayMemories Camera Apps™

-

Clear Image Zoom

Still images: Approx. 2x, Movies: Approx. 1.5x (4K), Approx. 2x (HD)

Digital zoom

Smart zoom (Still images): 35 mm full-frame: M: approx. 1.5x, S: approx. 2x / APS-C: M: approx. 1.3x, S: approx. 2x, Digital zoom (Still images): 35 mm full-frame: L: approx. 4x, M: approx. 6.1x, S: approx. 8x / APS-C: L: approx. 4x, M: approx. 5.2x, S: approx. 8x, Digital zoom (Movie): 35 mm full-frame: approx. 4x, APS-C: approx. 4x

Face Detection

Face Priority in AF, Face Priority in Multi Metering, Regist. Faces Priority

Self-Portrait Self-Timer

-

Others

Interval Recording, ISO AUTO Min. SS, Bright Monitoring, Copyright Info, Set File Name, Help guide, Video Light Mode, Zoom Ring Rotate

Type

Electronically-controlled, vertical-traverse, focal-plane type

Shutter Type

Mechanical shutter / Electronic shutter

Shutter Speed

Still images: Mechanical Shutter: 1/4000 to 30 s, Bulb, Electronic Shutter: 1/8000 to 30 s, Movies (NTSC mode): 1/4000 to 1/4 (1/3 steps), up to 1/60 in AUTO mode (up to 1/30 in Auto slow shutter mode), Movies (PAL mode): 1/4000 to 1/4 (1/3 steps), up to 1/50 in AUTO mode (up to 1/25 in Auto slow shutter mode)

Flash Sync. Speed

1/160 sec.

Electronic Front Curtain Shutter

Yes

Silent Shooting

Yes (ON/OFF)

Type

-

Guide No.

-

Flash coverage

-

Control

Pre-flash TTL[[F_DI0181]]

Flash Compensation

/- 3.0 EV (switchable between 1/3 and 1/2 EV steps)

Flash Modes

Flash off, Autoflash, Fill-flash, Slow Sync., Rear Sync., Red-eye reduction (on/off selectable), Wireless, Hi-speed sync.

Recycling Time

-

External Flash Compatibility

Sony α System Flash compatible with Multi Interface Shoe, attach the shoe adaptor for flash compatibility with the Auto-lock accessory shoe

FE Level Lock

Yes

Wireless Control

Yes (Light signal: Available with Fill-flash, Slow Sync., Hi-speed sync. / Radio signal: Available with Fill-flash, Rear Sync., Slow Sync., Hi-speed sync.)

Type

Image Sensor-Shift mechanism with 5-axis compensation (Compensation depends on lens specifications)

Compensation Effect

5 stops (based on CIPA standard. Pitch/yaw shake only. With Planar T* FE 50 mm F1.4 ZA lens mounted. Long exposure NR off)

Drive Modes

Single Shooting, Continuous shooting (Hi /Hi/Mid/Lo selectable), Self-timer, Self-timer (Cont.), Bracket: Single, Bracket: Cont., White Balance bracket, DRO bracket

Continuous Drive Speed (approx. max.)

Continuous shooting: Hi : 10fps, Hi: 8fps, Mid: 6fps, Lo: 3fps

No. of recordable frames (approx.)

JPEG Extra fine L: over 215 frames, JPEG Fine L: over 223 frames, JPEG Standard L: over 223 frames, RAW: over 115 frames, RAW & JPEG: over 86 frames, RAW (Uncompressed): over 45 frames, RAW (Uncompressed) & JPEG: over 39 frames

Self-Timer

10 s delay / 5 s delay / 2 s delay / Continuous self-time / Bracketing self-timer

Pixel Shift Multi Shooting

-

Photo Capture

Yes

Modes

Single (with or without shooting information Y RGB histogram & highlight / shadow warning), Index view, Enlarged display mode (L: 18.8x, M: 12.3x, S: 9.4x), Auto Review, Image orientation, Slideshow, Folder selection (Date / Still / XAVC S HD / XAVC S 4K), Protect, Rating, Display as Group

Compatible Standards

Exif Print, Print Image Matching III, DPOF setting

Type

Custom key settings, Programmable Setting (Body 3 sets /memory card 4 sets), My Dial Settings, My Menu, Reg Cust Shoot Set

Setting

Peripheral Shading, Chromatic Aberration, Distortion

PC Interface

Mass-storage / MTP

Multi/Micro USB Terminal

USB Type-C® SuperSpeed USB 5 Gbps (USB 3.2) compatible

Sync Terminal

-

Bluetooth®

Yes (Bluetooth® Standard Ver. 4.1 [2.4GHz band])

Multi Interface Shoe

Yes (with Digital Audio Interface)

Vertical Grip Connector

-

Mic Terminal

Yes (3.5 mm Stereo minijack)

Headphone Terminal

Yes (3.5 mm Stereo minijack)

LAN Terminal

-

FUNCTIONS

FTP Transfer Func. (Wi-Fi), View on Smartphone, Remote control via Smartphone, NFC One-touch remote, NFC One-touch sharing, PC Remote, BRAVIA Sync (Control for HDMI), PhotoTV HD

Microphone

Built-in, stereo

Speaker

Built-in, monaural

Supplied Battery

One rechargeable battery pack NP-FZ100

Battery Life (Still Images)

Approx. 680 shots (Viewfinder) / approx. 740 shots (LCD monitor) (CIPA standard)

Battery Life (Movie, actual recording)

Approx. 140 min (Viewfinder) / Approx. 140 min (LCD monitor) (CIPA standard)

Battery Life (Movie, continuous recording)

Approx. 220 min (Viewfinder) / Approx. 215 min (LCD monitor) (CIPA standard)

Internal Battery Charge

Yes

Power consumption with Viewfinder

Still images: approx. 2.9 W (with FE 28–60 mm F4–5.6 OSS lens attached), Movies: approx. 4.5 W (with FE 28–60 mm F4–5.6 OSS lens attached)

Power consumption with LCD screen

Still images: Approx. 2.7 W (with FE 28–60 mm F4-5.6 OSS lens attached), Movies: approx. 4.6 W (with FE 28–60 mm F4–5.6 OSS lens attached)

USB Power Supply

Yes

Weight (with battery and memory card included)

Approx. 509 g (approx. 1 lb 2 oz) (Body Only: Approx. 424 g [Approx. 15 oz])

Dimensions (W x H x D)

124 x 71 x 59 mm, 124 x 71.1 x 53.5 mm (5 x 2.8 x 2.32, 5 x 2.8 x 2.11) (from grip to monitor)

Operating Temperature

32 - 104 degrees F / 0 - 40 degrees C
